PWRspkr 15W
#58406-947
$79.95
Click for Details
- PWRspkr - Amplified Speaker
- Tilt mounting bracket
- (1) 6ft power cable with Powerpole® connectors
- (1) 1/8" Audio Cables, 6 ft.
- Owner's Manual
Capabilities
- High power 15 watt RMS linear power amplifier minimizes distortion at high sound levels
- Sharp bandpass filter with 300 Hz to 3.2 kHz pass band attenuates unneeded bass and treble sounds
- Adjustable gain control
- Power cable fitted with Powerpole® connectors
- Plugs into radio's speaker or headphone jack
- Ideal for use in truck or car for improved communication in noisy environment
Specifications
| Dimensions | 4.3" H x 5.5" W x 2.5" D 4.7" H x 6.5" W x 2.7" D when mounted |
| Power Requirements | 9 to 16VDC Current: 2A max w/ 13.8V supply Quiescent current 90mA typical |
| Sensitivity | 0.83 VRMS produces full output into 4 ohms (1 kHz signal, 13.8V supply) |
| Loudspeaker Driver | 4 in. treated paper cone 4 ohm impedance Rated Power: 20 watts |
| Power Amplifier - Integrated Circuit | Class AB Linear BTL (bridged-tied-load) circuit 15 watts RMS audio output into 4 ohms when powered by 13.8V supply Short circuit protected by shut down Over-heat protected by shut down Heat sink is the two PCB ground planes |
| Pre-Amplifier | Active four stage filter with gain Frequency response is flat 300 to 3.2kHz 18 dB/octave high-pass at 300 Hz (-3 dB) 18 dB/octave low-pass at 3.2 kHz (-3 dB) |
Quality Declaration
Product designed, tested and used by ham radio operators onsite.
Includes
- PWRspkr - Amplified Speaker
- Tilt mounting bracket
- (1) 6ft power cable with Powerpole® connectors
- (1) 1/8" Audio Cables, 6 ft.
- Owner's Manual
Powerpole® is a registered trademark of Anderson Power Products.
Powerpole® Connector Features & Benefits
- Genderless Housings: Provide simplified assembly and minimize the number of components
- Stackable Modular Housings: Available in four sizes to right size your connection need
- Connection Versatility: Contacts for wire, PCB, or busbar all fit into the same housings
- Low Resistance Connection: Silver or tin plated contacts inside housings that strongly force the contacts together
- Color Coded Housings: Help ensure that connectors are assembled and mated correctly
- Self Securing Design: Stainless steel springs create a robust force between the contacts that holds the connector in the mated condition, but allows it to be quickly disconnected.
Anderson Powerpole® Connectors and General Installation Tips
| Powerpole® Connectors | |||
|---|---|---|---|
| 15A | 30A | 45A | |
| Amps (UL) Per Pole | 0 to 55 | 0 to 55 | 0 to 55 |
| Volts (UL) Per Pole | 600 | 600 | 600 |
| Amps Continuous | 15 | 30 | 45 |
| Wire Gauge (AWG) | 20 - 16 | 16 - 12 | 14 - 10 |
| Touchsafe Polarized Housing |
Yes Yes |
Yes Yes |
Yes Yes |
| PDF Files Links |
Data Sheet https://www.andersonpower.com/ |
||
